Step Description
10. Return the server to operation.
11. Verify the installation. If any fault is present, you must correct
the fault and clear it from the server.
12. Review the root complex changes.
13. Review the PCIe card load balancing changes. Even though
the load balancing guidelines change with the u;pgrade, you
do not need to move any existing PCIe cards.
Related Information
"Processor Module Components" on page 19
■
"System Schematic" on page 41
■
"Detecting and Managing Faults" on page 25
■
"Removing Power From the Server" on page 50
■
"Servicing DIMMs" on page 69
■
"Processor Module Configuration" on page 57
■
"Remove a Processor Module or Processor Filler Module" on page 60
■
"Install a Processor Module or Processor Filler Module" on page 64
■
"Verify a Processor Module" on page 67
■
"Understanding PCIe Root Complex Connections" on page 165
■
"PCIe Card Configuration" on page 168
■
"Returning the Server to Operation" on page 201
■

Processor Module Configuration

Processor modules are accessed from the front of the server. In Oracle ILOM, the processor
modules are numbered PM0 and PM1, starting with the lower slot.
Processor Module Configuration
Link
"Returning the Server to Operation" on page 201
"Verify a Processor Module" on page 67
"Understanding PCIe Root Complex
Connections" on page 165
"PCIe Card Configuration" on page 168
Servicing Processor Modules 57
