Server Upgrade Process

"Returning the Server to Operation" on page 201
■
Server Upgrade Process
The SPARC T7-4 server supports two processor module configurations:
Fully-populated — Two processor modules
■
Half-populated— One processor module and one processor filler module
■
Processor modules are cold-service components that can be replaced only by qualified
service personnel. For the location of the processor modules, see
(Service)" on page
Caution -
electrostatic discharge. This discharge can cause failure of server components.
This table contains the steps for upgrading the server to a fully-populated configuration.
Step Description
1. Remove the upgrade components from their packaging, and
place them on an antistatic mat.
2. Remove the covers from the new processor module.
3. Remove all of the DIMM fillers in the processor module. The
steps to remove the DIMM fillers are the same as the steps for
removing DIMMs.
4. Verify that you have the correct DIMMs for your server. All of
the DIMMs must be either 16 or 32 GB, and they must match
the size and capacity of the DIMMs already installed in the
server.
5. Install the DIMMs.
6. Check the server for faults. If any fault is present, you must
correct the fault and clear it from the server before you can
continue with the upgrade.
7. Shut down the server.
8. Remove the processor filler module from Slot 1.
9. Install the new processor module in Slot 1.
56 SPARC T7-4 Server Service Manual • May 2017
14.
These service procedures require that you handle components that are sensitive to
"Front Panel Components
Link
"Remove a Processor Module or Processor Filler
Module" on page 60
"Remove a DIMM" on page 78
"Understanding DIMM Configurations" on page 69
"Install a DIMM" on page 80
"Check for Faults" on page 33
"Removing Power From the Server" on page 50
"Remove a Processor Module or Processor Filler
Module" on page 60
"Install a Processor Module or Processor Filler
Module" on page 64
