Install the Main Module
2.
Open the levers so that they are fully open.
Caution -
perform. Do not attempt to lift the main module alone.
Insert the main module into its slot in the server until the levers begin to engage.
3.
Press the levers back together, toward the center of the module, then press the
4.
levers firmly against the module to fully seat the module back into the server.
106
SPARC T7-4 Server Service Manual • May 2017
Due to the weight of the main module, the following step requires two people to
