Front Panel Controls and LEDs

No. LED
1 Locator LED and
button (white)
2 Server Service
Required LED
(amber)
3 Power OK LED
(green)
Icon or Label Description
You can turn on the Locator LED to identify a particular
server. When lit, the LED blinks rapidly. Turn on the Locator
LED by pressing the Locator button, or see
Server" on page 49.
The fmadm faulty command provides details about any
faults that cause this indicator to light. See
Faults" on page 33.
Under some fault conditions, individual component fault LEDs
are lit in addition to the Server Service Required LED.
Indicates these conditions:
■ Off – Server is not running in its normal state. Server power
might be off. The SPM might be running.
Detecting and Managing Faults
Checking for Faults
"Locate the
"Check for
