Press the green button near the front edge of the cover and slide the cover back and up off the
main module.
3.
Locate the DIMMs that need to be replaced.
See
"Determine Which DIMM Is Faulty (DIMM Fault LEDs)" on page
4.
Push down on the ejector tabs on each side of the DIMM until the DIMM is
released.
DIMMs and heat sinks on the motherboard might be hot.
Caution -
5.
Grasp the top corners of the faulty DIMM and lift it out of its slot.
Place the DIMM on an antistatic mat.
6.
7.
Repeat
Step 4
through
8.
Determine your next step:
Step 6
for any other DIMMs you intend to remove.
Remove a DIMM
76.
Servicing DIMMs
79
