412 A B: A
PPENDIX UTOMATED
B O I
RANCH FFICE NSTALLATION
Table 30 New Reservation Fields (continued)
Field Description
MAC address String: 3Com-Phone-2102 becomes Com-Phone-2102
(continued) Hexadecimal: 436f6d2d50686f6e652d32313032
String: 3Com-Phone-3100 becomes Com-Phone-3100
Hexadecimal: 436f6d2d50686f6e652d33313030
String: 3Com-Phone-3101 becomes Com-Phone-3101
Hexadecimal: 436f6d2d50686f6e652d33313031
String: 3Com-Phone-3102 becomes Com-Phone-3102
Hexadecimal: 436f6d2d50686f6e652d33313032
String: 3Com-Phone-3103 becomes Com-Phone-3103
Hexadecimal: 436f6d2d50686f6e652d33313033
Description Enter a description of your choosing.
Example: Reserved address for VCX Server in Branch 01.
Example: Reserved IP address for Media Gateway in Branch 01.
Example: Reserved IP address for 3Com 3102 Telephone.
Supported Enable the Both radio button.
types
The Windows 2003 server expects a valid MAC address in the MAC
address field. The Vendor Class Identifier strings (converted to
hexadecimal format) are longer than a normal MAC address so you may
see this warning message: "The Unique Identifier you have entered may
not be correct. Do you want to use this identifier anyway?" It is safe to
ignore this message.
Configuring DHCP Options for a Reservation
For each IP address reservation that you have created, follow the
procedures in this section to configure DHCP options 12, 60, 66, and 67.
Option 12 — Host Name
The host name option allows the DHCP server to supply a name for the
branch office VCX server or the Media Gateway that has sent the DCHP
request. 3Com suggests that you choose each host name to indicate the
office in which the host resides.
