Tools - 3Com VCX V7000 Installation Manual

22 C 1: P -I
HAPTER RE

Tools

Serial Cables
Terminal Emulation
Program
G
NSTALLATION UIDELINES
For branch servers, all software services use eth0.
CAUTION: The IBM X306m series servers treat eth0 as eth1 and eth1 as
eth0 interface.
All of the servers in VCX systems arrive from the factory configured to use
the server's serial port as the console connection. No keyboard or mouse
connections are enabled. To connect your PC to the VCX server, use a
"Serial Cables"
The null modem cable for IBM servers must have these characteristics:
DB9 female connector on each end
■
Sufficient length to reach from the PC to the VCX server
■
The serial cable for 3Com V6000 (Analog) and V6100 (Digital) servers
comes with the server. One end connects to the serial port (marked 1010)
on the connection module located in the middle lower portion of the
front panel.
CAUTION: Insert and remove the cable connector very gently when
attaching the cable to the V6000 front panel. The connector is fragile and
breaks easily.
To configure a VCX server, you must run a terminal emulation program
on your PC that is connected to the serial port on the VCX server. The
program must be configured for the PC serial port you want to use
(typically COM1 or COM2) and must have the parameters shown in
Table 4.
Table 4 Terminal Emulation Program Parameters
IBM x306m or x346 Servers
VT100 emulation mode
9600 Baud
8 data bits
1 stop bit
No parity
No flow control
and run a "Terminal Emulation Program"
3Com V6000 or V6100 Servers
VT100 emulation mode
115,200 Baud
8 data bits
1 stop bit
No parity
No flow control
on your PC.
