402 A B: A
PPENDIX UTOMATED
B O I
RANCH FFICE NSTALLATION
4 Click OK.
To create option 184 and add it to the list of DHCP options:
1 Right click the name of the Windows 2003 server, and in the menu that
appears, click Set Predefined Options.
2 In the Predefined Options and Values window that appears, click Add.
3 In the Option Type window that appears, enter this information:
Table 25 Option 184 Values
Field Description
Name Enter a name of your choice.
Example: Call Processor Downloader Options
Data type In the drop-down list, click Byte.
Array Enable the array check box.
NOTE: Enabling the array check box allows you to enter multiple
values.
Code 184
Description Enter a description of your choice:
Example: Call Processor download information
4 Click OK to accept the values that you have entered.
Options 6 and 42
Options 6 and 42 are predefined on a Windows 2003 server. Configure
these options at the system-wide level to apply the configuration
parameters to all scopes that you create.
Option 6 — Domain Name Server IP Address
To configure the IP address of one or more domain name servers:
1 Right click the name of the Windows 2003 server, and in the menu that
appears, click Set Predefined Options.
2 In the Predefined Options and Values window that appears, select 006
DNS Servers from the Option name drop down list.
3 In the lower area of the window, click Edit Array.
4 In the IP Address Array Editor window that appears:
