296 C 9: I
HAPTER NSTALLING
3Com 3103
Manager Telephone
D
EVICES
The easiest way to install any 3Com telephone assumes that the
telephone obtains an IP address from a DHCP server. If your network does
not provide IP addresses through a DHCP server, you must manually
configure the IP address of the telephone.
Configuring the 3103 Telephone with a DHCP Server
To configure the 3Com 3103 Manager Telephone:
1 Plug one end of a Category 5 Ethernet cable into the connector on the
3103 Manager Telephone.
2 Plug the other end of the Ethernet cable into the appropriate data jack on
your network.
3 Plug the power cord into an AC power receptacle.
4 Plug the other end of the power cord into the power connector on the
telephone.
5 Press the bottom button in the group of three buttons that are located on
the right side of the telephone display panel.
6 Use the up and down arrow buttons to scroll through the list of options.
7 When the selection dot is beside Set Primary PBX IP, press the Select
button, located below the word Select in the display panel.
8 Enter the IP address of the Primary VCX Call Processing Server.
VCX systems typically have two Call Processing servers. One is the primary
server and the other is the alternate server, which is available for fail-over
purposes.
9 Press # to save the new setting.
10 Press the bottom button in the group of three buttons that are located on
the right side of the telephone display panel.
11 Use the up and down arrow buttons to scroll through the list of options.
12 When the selection dot is beside Set Secondary PBX IP, press the Select
button, located below the word Select in the display panel.
13 Enter the IP address of the Secondary VCX Call Processing Server.
14 Press # to save the new setting.
