CDM-625A Advanced Satellite Modem
Telnet Command Line Interface (CLI) Operation
9.3.3 Home > Modem Submenu
Open the Modem submenu from the Home menu. This submenu contains the following options:
Hot
Configuration Page
Key
A Interface
B Modem TX
C
Modem RX
D Carrier-in-Carrier (CnC)
Adaptive Coding and
E
Modulation (ACM)
F Drop and Insert (D&I)
G Block Upconverter (BUC)
Low-Noise Block
H
Downconverter (LNB)
I
MEO (Medium Earth Orbit)
J Utilities
K Overhead
Press a hot key to access a configuration page. See the specified chapter section for further
configuration options. Otherwise, press [ESC] to return to the Home menu.
Function
Configure the Tx and Rx Framing Modes
Configure the unit's Tx parameters
Configure the unit's Rx parameters
Configure CnC FAST Option
Configure ACM FAST Option
Configure D&I parameters
Configure BUC parameters and view operating statistics
Configure LNB parameters and view operating statistics
MEO (Medium Earth Orbit) and its associated
functions are not supported in FW Ver. 1.2.4. Its
hot key and nested screen, while selectable
and viewable, are NON-FUNCTIONAL at this
time.
Configure and monitor a variety of unit operational settings
Configure ESC, IDR Backward Alarms, AUPC, and EDMAC
9–22
MN-CDM625A
Revision 4
Sect.
9.3.3.1
9.3.3.2
9.3.3.3
9.3.3.4
9.3.3.5
9.3.3.6
9.3.3.7
9.3.3.8
9.3.3.9
9.3.3.10
9.3.3.11
