Comtech EF Data CDM-625A Installation And Operation Manual page 70

CDM-625A Advanced Satellite Modem
Introduction
ESC++ (NO REED SOLOMON)
No FEC, BPSK
No FEC, O/QPSK
VITERBI, BPSK, 1/2
VITERBI, O/QPSK, 1/2
VITERBI, O/QPSK, 3/4
VITERBI, O/QPSK, 7/8
SEQUENTIAL, BPSK, 1/2
SEQUENTIAL, O/QPSK, 1/2
SEQUENTIAL, O/QPSK, 3/4
SEQUENTIAL, O/QPSK, 7/8
TRELLIS, 8PSK, 2/3
TPC, BPSK, 5/16
TPC, BPSK, 21/44 (aka 1/2)
TPC, O/QPSK, 21/44 (aka 1/2)
TPC, O/QPSK, 3/4
TPC, O/QPSK, 17/18 (aka 0.95)
TPC, O/QPSK, 7/8
TPC, 8PSK/8-QAM, 3/4
TPC, 8PSK/8-QAM 17/18 (aka 0.95)
TPC, 8PSK/8-QAM, 7/8
TPC, 16-QAM, 3/4
TPC, 16-QAM, 7/8
LDPC, BPSK, 1/2
LDPC, O/QPSK, 1/2
LDPC, O/QPSK, 3/4
LDPC, O/QPSK, 2/3
LDPC, 8PSK/8-QAM, 3/4
LDPC, 8PSK/8-QAM,2/3
LDPC, 16-QAM, 3/4
ESC++ (ANY REED SOLOMON)
VITERBI, BPSK, 1/2
VITERBI, O/QPSK, 1/2
VITERBI, O/QPSK, 3/4
VITERBI, O/QPSK, 7/8
SEQUENTIAL, BPSK, 1/2
SEQUENTIAL, O/QPSK, 1/2
SEQUENTIAL, O/QPSK, 3/4
SEQUENTIAL, O/QPSK, 7/8
TRELLIS, 8PSK, 2/3
VITERBI, 16-QAM, 3/4
VITERBI, 16-QAM, 7/8
Lower Limit (kbps)
64.0
64.0
64.0
64.0
64.0
64.0
64.0
64.0
64.0
64.0
64.0
64.0
64.0
64.0
64.0
64.0
64.0
64.0
64.0
64.0
64.0
64.0
64.0
64.0
64.0
64.0
64.0
64.0
64.0
Lower Limit (kbps)
64.0
64.0
64.0
64.0
64.0
64.0
64.0
64.0
64.0
64.0
64.0
1–28
MN-CDM625A
Revision 4
Upper Limit (kbps)
12304.6
24609.3
5921.0
12304.6
18457.0
21533.2
1024.0
2048.0
2048.0
2048.0
24609.3
3700.6
5651.9
11745.3
18457.0
23242.1
21533.2
24609.3
24609.3
24609.3
24609.3
24609.3
5921.0
12304.6
18457.0
16406.2
24609.3
24609.3
24609.3
Upper Limit (kbps)
5263.1
10937.5
16406.2
19140.6
1024.0
2048.0
2048.0
2048.0
21875.0
21875.0
21875.0
