CDM-625A Advanced Satellite Modem
Rear Panel Connectors and Pinouts
3.2.1

IF Connection Group

WARNING! THERE MAY BE DC VOLTAGES, UP TO A MAXIMUM OF 48 VOLTS,
PRESENT ON THE TYPE 'N' RX AND TX IF CONNECTORS.
3.2.1.1

Rx IF Connectors

3.2.1.2

Tx IF Connectors

Connector Type Description
Type 'N' Rx IF signal, L- band
BNC Rx IF signal, 70/140 MHz band
Connector Type Description
Type 'N' Tx IF signal, L- band
BNC Tx IF signal, 70/140 MHz band
3–5
MN-CDM625A
Revision 4
Direction
In
Direction
Out
