Comtech EF Data CDM-625A Installation And Operation Manual page 430

CDM-625A Advanced Satellite Modem
Telnet Command Line Interface (CLI) Operation
9.3.4.6 Home > Network > Managed Switch
Open the Managed Switch page from the Network submenu. This page contains the following
options:
Hot
Dialog Window
Key
A Header Compression
B
Payload Compression
C Encryption Feature
D Encryption Key Select
Press a hot key to open a dialog window. Otherwise, press [ESC] to return to the Network
submenu.
Option Entry
Use the ↑↓ arrow keys to select Disable, Layer 2 Only, or Layer
2 And 3
Typical for either entry – Use the ↑↓ arrow keys to select Disable
or Enable
Use the ↑↓ arrow keys to select Key 1 through Key 8, or
Random
9–50
MN-CDM625A
Revision 4
