Comtech EF Data CDM-625A Installation And Operation Manual page 355

CDM-625A Advanced Satellite Modem
Serial-based Remote Product Management
Command
Length of
Parameter (Instruction
Arguments
& Qualifier)
Radius RAT= 1 byte, 0 or 1
Server
Password Type
Radius RAS= Up to 64 bytes
Server Shared
Secret
Precision Time PTU= 1 byte
Protocol
Transport
Mode
Precision Time PTS= 15 bytes
Protocol
Unicast Master
Precision Time PTY= 2 bytes
Protocol
Unicast Sync
Interval
Port PME= 1 byte
Monitoring
Enable
Port PMS= 1 byte
Monitoring
Source Port
Description of Arguments
Command or Query.
Sets or returns the RADIUS Server password type in the form x, where
0=PAP
1=CHAP
EXAMPLE: <0/RAT=0
NOTE: Parameter available only through Telnet CLI. Command available at Administrator level only.
Command or Query.
Sets or returns the RADIUS Server shared secret
EXAMPLE: <0/RAS=comtech
NOTE: Parameter available only through Telnet CLI. Command available at Administrator level only.
Command or Query.
Sets or returns PTP Transport Mode in the form x, where:
0=Multicast
1=Unicast
Command or Query.
Sets or returns the PTP Unicast Master IP Address in the form xxx.xxx.xxx.xxx.
Command or Query.
Sets or returns the PTP Unicast Master IP Address in the form xx, where:
-6= 64 Messages per second
-5= 32 Messages per second
-4=16 Messages per second
-3=8 Messages per second
-2=4 Messages per second
-1=2 Messages per second
+0=1 Message per second
+1=1 Message every 2 seconds (default value)
Command or Query.
Sets or returns port monitoring in the form x, where:
0=Disabled
1=Enabled
NOTE: MAC Learning must be enabled to monitor properly.
EXAMPLE: <0/PME=0
Command or Query.
Sets or returns the port monitoring source (monitoring) port in the form x, where:
1=Port 1
2=Port 2
3=Port 3
4=Port 4
5=WAN
NOTES:
1) Source port and destination port must be different.
2) WAN (5) monitors Packet Processor traffic if it presents.
EXAMPLE: <0/PMS=1
8–41
MN-CDM625A
Revision 4
Query
Response to
(Instruction & Response to Query
Command
Qualifier)
RAT= RAT? RAT=x
RAT? (see Description of
RAT* Arguments)
RAT#
RAS= RAS? RAS=xxx...
RAS? (see Description of
RAS* Arguments)
RAS#
PTU= PTU? PTU=x
PTU? (see Description of
PTU* Arguments)
PTU#
PTS= PTS? PTS=xxx.xxx.xxx.xxx
PTS? (see Description of
PTS* Arguments)
PTS#
PTY= PTY? PTY=xx
PTY? (see Description of
PTY* Arguments)
PTY#
PME= PME? PME=x
PME? (see Description of
PME* Arguments)
PME#
PMS= PMS? PMS=x
PMS? (see Description of
PMS* Arguments)
PMS#
