Comtech EF Data CDM-625A Installation And Operation Manual page 351

CDM-625A Advanced Satellite Modem
Serial-based Remote Product Management
Command
Length of
Parameter (Instruction
Arguments
& Qualifier)
Rx BERT RBP= 1 byte
Pattern
BERT 10E-3 BKE= 1 byte, 0 or 1
Error Insert
BERT Restart BRM= None
Monitor
BERT Result in N/A 7 bytes, numeric
bit errors
BERT Result in N/A 6 bytes
average BER
Description of Arguments
Command or Query.
Sets or returns Rx BERT Pattern, in the form x, where:
0=space
1=mark
2=1:1
3=1:2
4=63
5=511
6=2047 (DEFAULT)
7=2047R (or 2047 Alternate)
8=Mil-188
9=2^15-1
A=2^20-1
B=2^23-1
EXAMPLE: <0/RBP=6 (Rx BERT Pattern is 2047)
Command or Query.
Inserts 10E-3 BER in the form x, where:
0=Off
1=On
EXAMPLE: <0/BKE=1
Command only.
This command takes no arguments. Forces restart of the BERT monitor.
EXAMPLE: <0/BRM=
Query only.
Returns BERT monitor results in bit errors.
NOTE: If bit errors exceed 9999999, then response to query is BRE=9999999.
Query only
Returns the value of the average BER in the form a.bEcx, where:
x.x=Value
Ec=Exponent
x=Indicator of Sync Loss (see Note 1).
NOTES:
1) A "*" in last byte means there was a loss of pattern synchronization since last restart, but now is synchronized. A "_"
(space) in last byte means pattern synchronization is achieved.
2) Returns 999999 if there's no sync in BERT monitor.
EXAMPLE 1: <0/BRR? >0/BRR=2.8E7 (indicates BER @ 2.8 x 10
EXAMPLE 2: <0/BRR? >0/BRR=3.4E5* (indicates BER @ 3.4 x 10
and in sync)
-7
, and there was a Sync Loss)
-5
8–37
MN-CDM625A
Revision 4
Query
Response to
(Instruction & Response to Query
Command
Qualifier)
RBP= RBP? RBP=x
RBP? (see Description of
RBP# Arguments)
BKE= BKE? BKE=x
BKE? (see Description of
BKE# Arguments)
BRM= N/A N/A
N/A BRE? BRE=xxxxxxx
N/A BRR? BRR=x.xEcx
