CDM-625A Advanced Satellite Modem
Serial-based Remote Product Management
Command
Number of
Parameter (Instruction
Arguments
& Qualifier)
Quad Drop & QDI= 73 bytes
Insert
Configuration Save CST= 1 byte, 0 thru 9
Configuration Load CLD= 1 byte, 0 thru 9
Description of Arguments
Command or Query.
Sets or returns Quad Drop & Insert (QDI) (E1-CCS only) in the form
pccddddddddddddddddddddddddddddddddCCssssssssssssssssssssssssssssssssmrrr, where:
p=Port number 1 thru 4
cc=Number of Drop Channels, 0-32. Used to decide Port p's TX Tributary Rate if Interface Type is QDI (TFM=8).
dddddddddddddddddddddddddddddddd=32 channels (bytes) defining Timeslot locations
CC=Number of Insert Channels, 0-32. Used to decide Port p's RX Tributary Rate if Interface Type is QDI (RFM=8).
ssssssssssssssssssssssssssssssss=32 channels (bytes) defining Timeslot locations
Typical for Drop or Insert Timeslot definition:
0=Unused
z=Timeslot 0 (zero)
1-9=Timeslots 1 through 9
A=Timeslot 10 through V=Timeslot 31
m=E1 Clock Sync/Async mode (Read/Write on Port 1 string, Read-Only on other Ports strings). This is NOT a per
port setting, but a global setting. 0=E1's are asynchronous, 1=E1's are synchronous.
r=Reserved (value fixed at 0)
EXAMPLE 1:
QDI=131123456789ABCDEFGHIJKLMNOPQRSTUV031123456789ABCDEFGHIJKLMNOPQRSTUV00000
(Port 1's Drop and Insert channels 1-31 each using timeslots 1-31. E1 clock mode is asynchronous (Read-Write using
Port 1 string).)
EXAMPLE 2:
QDI=3041234000000000000000000000000000004123400000000000000000000000000001000
(Port 3's Drop and Insert channels 1-4 each using timeslots 1-4. E1 clock mode is synchronous (Read-only parameter in
Port 3 string).)
NOTE: This command is a bit forgiving in the sense that the modem accepts the command even though the interface
type is other than Quad Drop & Insert. This is intentional for use with the CRS-300 switch for 1:N redundancy.
Command only.
Stores the current modem configuration in Configuration Memory location in the form x, where:
x=0 thru 9
EXAMPLE: <0/CST=4 (stores the current configuration in location 4)
Command only.
Retrieves a previously stored modem configuration from Configuration Memory location in the form x, where:
x=0 thru 9
EXAMPLE: <0/CLD=4 (loads modem configuration from location 4 as the active configuration)
8–47
MN-CDM625A
Revision 4
Query
Response to
(Instruction & Response to Query
Command
Qualifier)
QDI= QDI?p QDI=pccdddddddddddd
QDI? QDI?pn ddddddddddddddddddd
QDI* (where n=0 thru 9 dCCsssssssssssssssss
QDI# returns the QDI sssssssssssssssmrrr
portion of 1 of 10
stored (Returns current Quad
configurations for a D&I configuration of a
single port p) single port p)
CST= N/A N/A
CST?
CST*
CST#
CLD= N/A N/A
CLD?
CLD*
CLD#
