CDM-625A Advanced Satellite Modem
CDM-625A ODU (Transceiver, BUC, LNB) Operation
10.3.3.3.3.3.1.6
Info: Tx:Off
This screen displays the Tx and Rx states, Frequencies, and Attenuation, and the reference.
10.3.3.3.3.3.1.7
Info:
This screen displays the HPA and LNA operational and fault logic summary settings.
Note that the Rx Band information is not shown for the KST-2000A.
10.3.3.3.3.3.1.8
M&C:
Use the arrow keys to view the Up-Converter, Down-Converter and HPA assembly and
▲▼
serial numbers as well as their firmware numbers/versions.
10.3.3.3.3.3.1.9
Current Status:
This is Summary Status information. Use the
Supplies, Down, HPA, or LNA, and then press ENTER. A detailed status screen, similar to the
following examples, is then shown:
Up-Converter:
Reference:Warm
AGC Status:
ODU: FSK-control  KST  Information  Tx+Rx-Param
13955MHz
Rx: 11950MHz
ODU: FSK-control  KST  Information  Misc
HPA:Off
Band:B LNA:Off
ODU: FSK-control  KST  Information  Numbers
F/W:9364-1B
assy:9357-1A
ODU: FSK-control  KST  Alarms
P-Supplies:OK
Comms:OK
Over-Temp:OK
Source:IntT Xref-Lock:NA
Loop-Conv:OK
10dB
20dB
Flt-Logic:No-Summ
FLT-Logic:Summary
VER:01.01.03
S/N:021476493
Up:OK Ref:OK
Dn:OK HPA:OK
◄ ► arrow keys to select Up, Ref, AGC, Power-
L-Synth:OK
Ku-Synth:OK
72M-Lock:OK Range:NA
Phase:NA
Excess-Power-In:OK
Insuff-Power-In:OK
10–24
MN-CDM625A
Ref:087
AGC:OK
LNA:OK
Revision 4
