CDM-625A Advanced Satellite Modem
Ethernet-based Remote Product Management
Column
Payload Comp.
Encryption
Encryption
Key
Click [Submit Changes] to save.
Add New Route
This section allows you to directly add a route entry using text boxes and drop-down lists as
described previously for the Route Table (Edit) section.
Click [Add Entry] to save. Note that, when a new route is added, the index automatically
increments to the next available number.
Delete Route
Enter Route Index to Delete, and then click [Delete Entry] once all changes have been made in
this section. The specified route entry will then be deleted from the route table.
Description
When the optional Payload Compression FAST feature is available, use the drop-down list
to Disable or Enable operations.
When the optional AES Encryption FAST feature is available, use the drop-down list to
Disable or Enable operations.
With AES Encryption disabled, all routed traffic is transmitted 'in the
clear' regardless of the Encryption Key specified in the Route Table.
With encryption enabled, use the drop-down list to select Key 1 through Key 8 (assigned
using the 'Configuration | WAN | Encryption' page, Sect. 7.5.4.3.5.3) or Random Key.
You must program all eight encryption and decryption keys before
selecting Random Key – otherwise, the modem will select any of the
eight allotted keys, even if a key is currently clear (set to all zeroes).
