CDM-625A Advanced Satellite Modem
Serial-based Remote Product Management
Command
Length of
Parameter (Instruction
Argument
& Qualifier)
Rx Clock RCK= 1 byte, 0 thru 3
Source
Rx Clock Invert RCI= 1 byte, 0 or 1
Eb/No Alarm EBA= 4 bytes
Point
Rx Buffer Size RBS= 5 bytes
Rx Audio RVL= 4 bytes
Volume Control
Receive RTE= 1 byte, 0 or 1
Terrestrial
Alarm Enable
Insert Type ITY= 1 byte, 0 thru 3
Rx Ternary RTC= 1 byte, 0 thru 3
Code
Description of Arguments
Command or Query.
Sets or returns Rx Clock Source in the form x, where:
0=Rx Satellite
1=Tx-Terrestrial
2=Internal(SCT)
3=INSERT (command valid only when Rx framing is Insert or D&I++ and interface is G.703 or set for D&I loop)
EXAMPLE: <0/RCK=1 (selects Tx-Terrestrial)
Command or Query.
Sets or returns Invert Receive Clock, in the form x, where:
0=Normal
1=Inverted
Command or Query.
Sets or returns Eb/No alarm point in the form xx.x, where:
xx.x=Value, in dB, from 0.1 to 16
Resolution=0.1 dB
EXAMPLE: <0/EBA=12.3
Command or Query.
Sets or returns Rx Buffer Size in the form xxxxx, where:
xxxxx=Value, in 2-byte steps (unless other limitations apply), from 00016 to 32768 bytes
(See Chapter 6, Sect. 6.2.1.5.2)
EXAMPLE: <0/RBS=08192 (selects 8192 bytes)
Command or Query. (Audio/IDR parameters)
Sets or returns Rx Audio Volume control in the form aabb, where:
aa=Rx 1 volume control value, in dB: Valid values are -6, -4, -2, +0, +2, +4, +6, +8;
bb=Rx 2 volume control value, in dB: Valid values are -6, -4, -2, +0, +2, +4, +6, +8.
EXAMPLE: <0/RVL=-2+4 (sets Rx 1 to -2 dB and Rx 2 to +4 dB)
Command or Query. (INSERT mode parameter)
Sets or returns Receive Terrestrial Alarm Enable conditions in the form x, where:
0=Disables the alarm
1=Enables the alarm.
EXAMPLE: <0/RTE=0 (disables the alarm).
Command or Query. (INSERT/D&I++/QDI parameter)
Sets or returns Insert Type, in the form x, where:
0=T1-D4
1=T1-ESF
2=E1-CCS
3=E1-CAS
Command or Query. (G.703 parameter)
Sets or returns Rx Ternary Code in the form x, where:
0=AMI
1=B8ZS
2=B6ZS
3=HDB3
EXAMPLE: <0/ RTC=1 (selects B8ZS)
8–24
MN-CDM625A
Revision 4
Query
Response to
(Instruction & Response to Query
Command
Qualifier)
RCK= RCK? RCK=x
RCK?
RCK* (see Description of
RCK# Arguments)
RCI= RCI? RCI=x
RCI?
RCI* (see Description of
RCI# Arguments)
EBA= EBA? EBA=xx.x
EBA?
EBA* (see Description of
EBA# Arguments)
RBS= RBS? RBS=xxxxx
RBS?
RBS* (see Description of
RBS# Arguments)
RVL= RVL? RVL=aabb
RVL?
RVL* (see Description of
RVL# Arguments)
RTE= RTE? RTE=x
RTE?
RTE* (see Description of
RTE# Arguments)
ITY= ITY? ITY=x
ITY?
ITY* (see Description of
ITY# Arguments)
RTC= RTC? RTC=x
RTC?
RTC* (see Description of
RTC# Arguments)
