Comtech EF Data CDM-625A Installation And Operation Manual page 343

CDM-625A Advanced Satellite Modem
Serial-based Remote Product Management
Command
Length of
Parameter (Instruction
Arguments
& Qualifier)
One Ti m e OTO= 1 byte, 0 or 1
EDMAC Slave
Overwrite
External EFR= 1 byte, 0 thru 6
Frequency
Reference
Exception –
600L Emulation:
MRC=
Adjustment for ADJ= 4 bytes, numeric
Internal 10MHz
High- stability
Reference
Warm-up Delay WRM= 1 byte, 0 or 1
Countdown of CTD= 3 bytes, numeric
Warm-up Delay
remaining
Unit Test Mode TST= 1 byte, 0 thru 6
Description of Arguments
Command or Query.
Sets or returns One Time Overwrite to EDMAC Slave modem in the form x, where:
0=Off
1=On
EXAMPLE 1: OTO=0 disables One Time Overwrite – EDMAC Slave modem may only remotely accept EDMAC
command from EDMAC Master modem.
EXAMPLE 2: OTO=1 enables One Time Overwrite – EDMAC Slave modem may locally accept ONE remote control
command.
Command or Query.
Sets or returns the External Frequency Reference in the form x, where:
0=Internal 10MHz (DEFAULT)
1=External 1 MHz
2=External 2 MHz
3=External 5 MHz
4=External 10 MHz
5=spare
6=Internal 10MHz plus output (this means that the Reference is available on the "Ext Ref" rear connector (small
rear-panel LED indicates when ON))
Command or Query.
Sets or returns fine adjustment of the Internal 10MHz Reference on the High-Stability Frequency Reference module in the
form sddd, where:
s=sign (+ or –)
ddd=Value, 0-999.
Command or Query. (Hi-Stability Frequency Reference parameter)
Sets or returns the High-Stability Frequency Reference warm-up delay parameter in the form x, where:
0=Delay off (instant on)
1=Warm-up Delay on
Command or Query. (Hi-Stability Frequency Reference parameter)
Sets or returns the High-Stability Frequency Reference countdown parameter in the form xxx, where:
xxx=countdown of the number of seconds remaining of the Warm-up time.
NOTE: As a command, the only permitted format is CTD=000, which abandons the delay.
Command or Query.
Unit Test Mode, where:
0=Normal Mode (no test)
1=Tx CW
2=Tx Alternating 1,0 Pattern
3=IF Loopback
4=RF Loopback
5=Digital Loopback
6=I/O Loopback
EXAMPLE: <0/TST=3 (IF Loopback)
8–29
MN-CDM625A
Revision 4
Query
Response to
(Instruction & Response to Query
Command
Qualifier)
OTO= OTO? OTO=x
OTO?
OTO* (see Description of
OTO# Arguments)
EFR= EFR? EFR=x
EFR? (see Description of
EFR* Arguments)
EFR#
Exception –
600L Emulation:
MRC=
MRC? Exception – Exception –
MRC* 600L Emulation: 600L Emulation:
MRC# MRC=? MRC=x
ADJ= ADJ? ADJ=sddd
ADJ? (see Description of
ADJ* Arguments)
ADJ#
WRM= WRM? WRM=x
WRM? (see Description of
WRM* Arguments)
WRM#
CTD= CTD? CTD=xxx
CTD? (see Description of
CTD* Arguments)
CTD#
TST= TST? TST=x
TST? (see Description of
TST* Arguments)
TST#
