CDM-625A Advanced Satellite Modem
CDM-625A ODU (Transceiver, BUC, LNB) Operation
10.5.1.2 Home > Outdoor Unit (ODU) Submenu
After configuring the CDM-625A for 70/140 MHz operation, you may use the 'ODU (Outdoor
Unit)' pages to control and monitor the CSAT-5060 Outdoor Unit that is connected via FSK to the
CDM-625A.
Open the Outdoor Unit (ODU) submenu from the Home menu. This submenu contains the
following options:
Hot
Dialog Window
Key
A
ODU Comms Enabled
B CSAT-5060
Press a hot key to open the dialog window or the submenu. Otherwise, press [ESC] to return to
the Home submenu.
Option Entry
Use the ↑↓ arrow keys to select Disabled or Enabled
Open the CSAT-5060 submenu – See Sect. 10.5.1.2.1
10–54
MN-CDM625A
Revision 4
