Comtech EF Data CDM-625A Installation And Operation Manual page 360

CDM-625A Advanced Satellite Modem
Serial-based Remote Product Management
Command
Number of
Parameter (Instruction
Arguments
& Qualifier)
Drop & Insert DNI= 51 bytes
Drop & Insert DIC= 67 bytes
Configuration
(31 channels)
Description of Arguments
Command or Query. (D&I only)
Sets or returns D&I in the form ddddddddddddddddddddddddtiiiiiiiiiiiiiiiiiiiiiiiiTL, where:
25 bytes of Drop information (ddddddddddddddddddddddddt) where:
d=24 channels (bytes) defining Drop Timeslot information
t=Drop type: 0=T1-D4, 1=T1-ESF, 2=E1-CCS, 3=E1-CAS, as DTY
25 bytes of Insert information (iiiiiiiiiiiiiiiiiiiiiiiiT) where:
i=24 channels (bytes) defining Insert Timeslot infromation
T=Insert type: 0=T1-D4, 1=T1-ESF, 2=E1-CCS, 3=E1-CAS, as ITY
Typical for Drop or Insert Timeslot definition:
0=Unused
z=Timeslot 0 (zero)
1-9=Timeslots 1 through 9
A=Timeslot 10 through V=Timeslot 31
L=D&I Internal Loop: 0=OFF, 1=ON
EXAMPLE: <0/DNI=123456789ABC0000000000003123456789ABC00000000000031
(Drop channels 1-12 using timeslots 1-12, and unused channels 13-24. Same for Insert. E1-CAS, D&I types,
Internal Loop ON).
NOTE: If framing is D&I and data rate is 1920 kbps and DNI Type is E1-CCS or E1-CAS, then channels cannot be
programmed (i.e. FIXED CHANNEL MODE).The DNI? response will display all 'x' in the time-slot positions.
Command or Query. (D&I++ only) (Not available in 600/L Emulation mode)
Sets or returns D&I++ in the form dddddddddddddddddddddddddddddddxxsssssssssssssssssssssssssssssssxxL where:
31 bytes of Drop Information (dddddddddddddddddddddddddddddddxx) where:
d=31 channels (bytes) defining Drop Timeslot information
PLUS xx=spares
31 bytes of Insert Information (sssssssssssssssssssssssssssssssxx) where:
s=31 channels (bytes) defining Insert Timeslot information
PLUS xx=spares
Typical for Drop or Insert Timeslot definition:
0=Unused
z=Timeslot 0 (zero)
1-9=Timeslots 1 through 9
A=Timeslot 10 through V=Timeslot 31
L=D&I Internal Loop: 0=OFF, 1=ON
EXAMPLE: <0/DIC=123456789ABCDEFGHIJKLMNOPQRSTUVxx123456789ABCDEFGHIJKLMNOPQRSTUVxx0
(Drop channels 1-32 using timeslots 1-31 and timeslot zero. Same for Insert. E1-CCS, Internal Loop Off.)
8–46
MN-CDM625A
Revision 4
Query
Response to
(Instruction & Response to Query
Command
Qualifier)
DNI= DNI? DNI=dddddddddddddd
DNI? DNI?n ddddddddddtiiiiiiiiiiiiiiiiiiiiiii
DNI* (where n=0 thru 9. iTL
DNI# Returns the DNI (see Description of
portion of 1 of 10 Arguments)
stored
configurations) (Returns current D&I
Configuration)
DIC= DIC? DIC=dddddddddddddd
DIC? DIC?n dddddddddddddddddxx
DIC* (where n=0 thru 9. sssssssssssssssssssss
DIC# Returns the DIC ssssssssssxxL
portion of 1 of 10 (see Description of
stored Arguments)
configurations)
