CDM-625A Advanced Satellite Modem
Serial-based Remote Product Management
Command
Length of
Parameter (Instruction
Arguments
& Qualifier)
...Retrieve next
five unread
Stored Events
(cont.)
Clear All CAE= None
Stored Events
Initialize Stored IEP= None
Events Pointer
Statistics SSI= 1 byte, numerical
Sample Interval
Number of N/A 3 bytes
Unread stored
Statistics
Retrieve next N/A 135 bytes
five unread
Stored
Statistics
Description of Arguments
C=Fault Code number, as in FLT? or Info Code, which may be:
0=Power Off
1=Power On
2=Log Cleared
3=Global Config Change
4=Redundancy Config Change
5=Fractional CnC License is expiring.
6=Time Limited CnC License is expiring.
7=Fractional CnC is in use.
ddmmyy=date stamp.
hhmmss=time stamp.
NOTES:
1) If there are less than five retrievable events, the remaining positions are padded with zeros.
2) If there are no new events, the response is RNE*.
Command only.
This command takes no arguments. Forces the modem to clear the firmware events log.
EXAMPLE: <0/CAE=
Command only.
Resets internal pointer to allow RNE? queries to start at the beginning of the stored events log.
Command or Query.
Sets or returns the sample interval for the Statistics Logging Function in the form x, where:
x=0 thru 9 in 10 minute steps.
NOTE: Set this parameter to 0 thru disable the statistics logging function.
EXAMPLE: <0/SSI=3 (interval is set at 30 minutes)
Query only.
Returns the number of stored statistics that remain unread over remote control, in the form xxx, where xxx=000-255.
EXAMPLE: <0/NUS? >0/NUS=187
Query only.
Returns the oldest five stored Statistics that have not yet been read, in the form [CR]sub-body[CR]sub-body[CR]
sub-body[CR]sub-body[CR]sub-body where:
For all non-ACM modes, the statistics sub-body is defined as AA.ABB.BC.CD.Dddmmyyhhmmss where:
•
AA.A=Minimum Eb/No during sample period.
BB.B=Average Eb/No during sample period.
C.C=Maximum Tx Power Level Increase during sample period.
D.D=Average Tx Power Level Increase during sample period.
ddmmyy=date stamp.
hhmmss=time stamp.
In VersaFEC ACM (IP-ACM) mode, the statistics sub-body is defined as AA.ABB.BC,DE,Fddmmyyhhmmss,
•
where:
AA.A=Minimum SNR during sample period.
BB.B=Average SNR during sample period.
C=IP-ACM Rx ModCod that was current at time the statistic entry was logged.
D=Maximum Rx ModCod in hex during sample period.
E=Minimum Rx ModCod in hex during sample period.
8–31
MN-CDM625A
Revision 4
Query
Response to
(Instruction & Response to Query
Command
Qualifier)
CAE= N/A N/A
CAE?
CAE*
CAE#
IEP= N/A N/A
IEP#
SSI= SSI? SSI=x
SSI? (see Description of
SSI* Arguments)
SSI#
N/A NUS? NUS=xxx
(see Description of
Arguments)
N/A RNS? RNS=[CR]sub-
body[CR]sub-
body[CR]
sub-body[CR]sub-
body[CR]sub-body
(see Description of
Arguments)
