Comtech EF Data CDM-625A Installation And Operation Manual page 407

CDM-625A Advanced Satellite Modem
Telnet Command Line Interface (CLI) Operation
Hot
Dialog Window
Key
F Rx Frequency
G Rx Spectrum Invert
H Rx Descrambler
I
Rx Acq Sweep Range
Rx Reed-Solomon
J
Decoding
K Rx Data Invert
L Rx Data Clock Invert
M Rx Ternary Code
N
Rx EbNo Alarm Point
O
Rx Equalizer Enable
P Rx Submux
Q
Rx Submux Ratio
R Rx Filter Rolloff Factor
Press a hot key to open a dialog window. Otherwise, press [ESC] to return to the Modem
submenu.
Option Entry
Enter an Rx Frequency as follows:
Range 1 – From 50.0000 to 180.0000 MHz
•
Range 2 – From 950.0000 to 2250.0000 MHz
•
Use the ↑↓ arrow keys to select Normal or Inverted
Use the ↑↓ arrow keys to select Off, Normal, or IESS315
Enter a value from 1 to 200 kHz
Use the ↑↓ arrow keys to select Normal, IESS410, EF Data, or IBS
Typical for either entry – Use the ↑↓ arrow keys to select Normal or Inverted
Use the ↑↓ arrow keys to select AMI, B8zs, B6zs, or Hdb3
Enter a value from 0.1 to 16.0 dB
Use the ↑↓ arrow keys to select Disabled or Enabled
Use the ↑↓ arrow keys to select Off or On
Use the ↑↓ arrow keys to select the IP/Synchronous setting:
• 1/9 • 1/8 • 1/7
• 2/7 • 1/3 • 2/5
• 2/3 • 3/4 • 4/5
• 3/2 • 5/3 • 2/1
• 7/2 • 4/1 • 5/1
• 9/1 • 1/59 • 1/39
Use the ↑↓ arrow keys to select an Rx Rolloff Factor of 0.12 or 0.35
9–27
MN-CDM625A
Revision 4
• 1/6 • 1/5 • 1/4
• 3/7 • 1/2 • 3/5
• 1/1 • 5/4 • 4/3
• 7/3 • 5/2 • 3/1
• 6/1 • 7/1 • 8/1
• 1/19
