Comtech EF Data CDM-625A Installation And Operation Manual page 331

CDM-625A Advanced Satellite Modem
Serial-based Remote Product Management
Command
Parameter Number of
(Instruction
Type Arguments
& Qualifier)
Drop Type DTY= 1 byte, 0 thru 3
Tx Drop DTS= 3 bytes
Timeslot
Tx Ternary TTC= 1 byte, 0 thru 3
Code
Transmit TBA= 4 bytes, each 0
Backward thru 2
Alarms Enable
Transmit ESC TET= 1 byte, 0 or 1
Type
TX LO TLO= 6 bytes
Frequency
Tx Satellite N/A 10 bytes
(Terminal)
Frequency
Tx Information N/A 9 bytes, numeric
Rate
Description of Arguments
Command or Query. (DROP/D&I++/QDI parameter)
Sets or returns Drop Type in the form x, where:
0=T1-D4
1=T1-ESF
2=E1-CCS
3=E1-CAS
Command or Query. (DROP parameter)
(Note different format between command and query.)
Sets or returns Tx Drop timeslot – Command format is in the form xxy, where:
xx=Channel 01 through 24
y=timeslot: 0-9, A=10, B=11, C=12, D=13,...V=31
Command or Query. (G.703 parameter)
Sets or returns Tx Ternary Code in the form x, where:
0=AMI
1=B8ZS
2=B6ZS
3=HDB3
EXAMPLE: <0/ TTC=1 (selects B8ZS)
Command or Query. (IDR parameter)
Sets or returns Tx Backward Alarm Enable in the form xxxx, where:
0=Disable
1=Enable Internal (S/W)
2=Enable External (H/W)
EXAMPLE: <0/TBA=0120
Command or Query. (IDR parameter)
Sets or returns IDR ESC Type in the form x, where:
0=64k data channel
1=2 Audio channels
Command or Query.
Sets or returns Tx LO frequency information in the form xxxxxs, where:
xxxxx=LO frequency, in MHz, from 3000 thru 65000, or 00000 (OFF)
s=sign for the MIX (+ or –)
NOTE: Terminal Frequency=LO ± TFQ
EXAMPLE: <0/TLO=12000+ (BUC LO is 12GHz, low-side mix)
Query only.
Returns terminal (aka satellite) Tx Frequency, which is the frequency transmitted to the satellite, the form xxxxx.xxxx.
Resolution=100 Hz
NOTE: Returns 00000.0000 if LO is zero
EXAMPLE: <0/TTF? >0/TTF=11650.2249
Query only.
Allows remote access to the Aggregate Tx Information Rate in the form ddddd.ddd
8–17
MN-CDM625A
Revision 4
Query
Response to
(Instruction & Response to Query
Command
Qualifier)
DTY= DTY? DTY=x
DTY?
DTY* (see Description of
DTY# Arguments)
DTS= DTS? DTS=yyyyyyyyyyyyyyyy
DTS? yyyyyyyy
DTS* indicating all 24 Drop
DTS# timeslots values
associated with the 24
Tx Satellite channels.
TTC= TTC? TTC=x
TTC?
TTC* (see Description of
TTC# Arguments)
TBA= TBA? TBA=xxxx
TBA?
TBA* Position indicates
TBA# backward alarm
numbers: 1234
TET= TET? TET=x
TET?
TET* (see Description of
TET# Arguments)
TLO= TLO? TLO=xxxxxs
TLO?
TLO* (see Description of
TLO# Arguments)
N/A TTF? TTF=xxxxx.xxxx
(see Description of
Arguments)
TIR? TIR? TIR=ddddd.ddd
TIR=
TIR* (see Description of
TIR# Arguments)
