GPIB interface
The GPIB interface allows you to use the 882 as a programmable video signal source in a
larger automated test system. The GPIB connector pinouts are listed in the following table.
Pin
Signal
Pin
1
DIO1
7
2
DIO2
8
3
DIO3
9
4
DIO4
10
5
EOI
11
6
DAV
12
Signal
Pin
Signal
NRFD
13
DIO5
NDAC
14
DIO6
IFC
15
DIO7
SRQ
16
DIO8
ATN
17
REN
Shield
18
Shield
Pin
Signal
19
Shield
20
Shield
21
Shield
22
Shield
23
Shield
24
Signal Ground
