Chapter 1 Getting Started
6
VGA interface
The VGA interface, available on the model 882C generator, outputs analog video for
testing analog video displays. The following table describes the VGA connector pinouts.
Pin
Signal
1
Analog Red Video
2
Analog Green Video 7
3
Analog Blue Video
4
No Connection
5
Digital Ground
HDMI interface
The HDMI interface emulates an HDMI-compliant video display. The HDMI connector
pinouts are shown in the following table.
HDMI Type A Connector Pinouts
Signal
TMDS Data 2+
TMDS Data2 Shield
TMDS Data2-
TMDS Data1+
TMDS Data1 Shield
TMDS Data1-
Special Sync interface
Use the Special connector to output frame sync, line sync, composite sync, or a special
probe pulse. For more information, see Chapter 14,
S-Video interface
The 882 generator has an S-Video connector labeled "S-VIDEO." This is a miniDIN
connector that emulates an S-Video compliant source for outputting composite TV signal.
Composite video BNC
The 882 generator has a composite TV BNC connector labeled "CVBS." This interface
emulates an analog composite TV source.
Pin
Signal
6
Analog Red Video Ground
Analog Green Video Ground 12
8
Analog Blue Video Ground
9
DDC/EDID +5 Vdc Out
10
Digital Ground
Pin
Signal
7
TMDS Data0+
8
TMDS Data0 Shield
9
TMDS Data0-
10
TMDS Clock+
11
TMDS Clock Shield
12
TMDS Clock-
Pin
Signal
11
No Connection
DDC/EDID Serial Data
13
Horizontal Sync
14
Vertical Sync
15
DDC/EDID Data Clock
Pin
Signal
13
CEC
14
Reserved (N.C.)
15
SCL
16
SDA
17
DDC/SEC Ground
18
+5 V Power
19
Hot Plug Detect
"Using Special Sync
Output."
