Chapter 1 Getting Started
12
means that DSS is selected, the + sign next to SyncOnG means that this option is
enabled, and the - signs next to Pedestal, SyncOnR, and SyncOnB mean that these
options are disabled. If you press the soft key adjacent to SyncOnR, the - will change to a
+, indicating the option is now enabled.
ACS SyncOnR-
DCS SyncOnG+
*DSS SyncOnB-
-Pedestal
The Settings key enables you to view or set a parameter to a value. For example, the
screen below shows the settings for the video signal of a format. To change the value of
the XVSI, AVSI, or DVSI setting, press the soft keys next to the arrows on the bottom row
of the 882's display until the blinking cursor is on the value you want to change. Increment
the value up or down by pressing the + and - keys.
Video Signal
Interface
XVSI AVSI DVSI
<- 1 3
To see other settings for the format, press the soft key adjacent to the arrows. If you press
the soft key next to the arrow by Video Signal, you will see the settings for Video Timing. If
you press the soft key next to the arrow by Interface, you will see the settings for
Synchronization.
->
->
0 ->
