▼ Verify Operation of Slide-Rails and
CMA
Use the following procedure to ensure that the slide-rails and CMA are operating
correctly.
Note – Two people should perform this procedure: one to move the server in and
out of the rack, and one to observe the cables and CMA.
1. To prevent the rack from tipping forward when the server is extended, extend
all rack anti-tilt devices.
Caution – To reduce the risk of personal injury, stabilize the rack cabinet and extend
all anti-tilt devices before extending the server from the rack.
For instructions for stabilizing the rack, see
page 43.
2. Slowly pull the server out of the rack until the slide-rails reach their stops.
3. Inspect the attached cables for any binding or kinks.
4. Verify that the CMA extends fully with the slide-rails.
5. To return the server to the rack:
a. Simultaneously pull and hold the two green release tabs (one on each side of
of the server) toward the front of the server while you push the server into
the rack. As you push the server into the rack, verify that the CMA retracts
without binding.
Note – To pull the green release tab, place your finger in the center of the tab, not on
the end, and apply pressure as you pull the tab toward the front of the server.
"Stabilize the Rack for Installation" on
Installing the Server Into a Rack 73
