Server Components - Sun Microsystems Server X4-2 Installation Manual

Server Components

TABLE:
Feature
Processor
Memory
Storage drives
PCI Express (PCIe)
I/O slots
Internal HBA
20 Sun Server X4-2 Installation Guide • February 2014
Sun Server X4-2 Components
Description
One or two processors with four integrated DDR3 memory
controllers per processor. Processors with the following capabilities
are supported:
• 2.7 GHz, 12-core, 130W
• 3.0 GHz, 10-core, 130W
• 2.6 GHz, 8-core, 95W
• 2.6 GHz, 6-core, 80W
• 2.5 GHz, 4-core, 80W
Up to 8 DIMMs per processor for a maximum of 16 DDR3 DIMMs
and a maximum of 512 GB of memory are supported in
dual-processor systems. RDIMMs (8 GB and 16 GB) and LRDIMMs
(32 GB) are supported.
Note - A maximum of 8 DIMMs and a maximum of 256-GB of
memory are supported in single-processor systems.
Storage drive configurations can comprise both spinning media hard
disk drives (HDDs) or solid state drives (SSDs). Configurations
include:
• Up to eight 2.5-inch hot-pluggable SAS HDDs/SATA SSDs
• Up to four 2.5-inch hot-pluggable SAS HDDs/SATA SSDs with a
DVD
Caution - In Oracle Engineered Systems, storage drive 7 might be
populated with a remote battery module for the host bus adapter
(HBA) card. The battery module is not a customer-replaceable unit
and should not be removed or replaced by customers. For more
information, refer to the
Module" on page
Three PCIe Gen3 slots that accommodate low-profile PCIe cards.
• Slot 1: x16 electrical interface
• Slots 2 and 3: x8 electrical interface
Note - PCIe slot 1 is nonfunctional in single-processor systems.
One dedicated PCIe Gen3 slot for use with an optional internal-only
host bus adapter (HBA) card. This internal HBA is used to control
and manage the storage drives.
Sun Server X4-2 Service Manual, "Battery
20.
