Configuring RAID in UEFI BIOS Boot Mode With
the Sun Storage 6 Gb SAS PCIe RAID Internal
HBA
The BIOS RAID configuration utilities support configuring RAID with the server set
to UEFI BIOS Boot Mode.
Note – Some operating systems and virtual machine software only support the
Legacy BIOS Boot Mode. For a list of operating systems and virtual machine software
that support UEFI BIOS Boot Mode, see
"Configure RAID in UEFI BIOS Boot Mode With the Sun Storage 6 Gb SAS PCIe
■
RAID Internal HBA" on page 134
▼ Configure RAID in UEFI BIOS Boot Mode With the Sun
Storage 6 Gb SAS PCIe RAID Internal HBA
1. Power on or reset the server.
For example, to reset the server:
■
■
■
The power-on self-test (POST) sequence begins.
2. To enter the BIOS Setup Utility, press the F2 key (Ctrl+E from a serial
connection) when prompted and while the BIOS is running the power-on
self-tests (POST).
After a few moments, the BIOS Setup Utility appears.
3. Use the right arrow key to navigate to UEFI Driver Control menu.
The UEFI Driver Control menu appears.
134 Sun Server X4-2 Installation Guide • February 2014
From the local server, press the Power button (approximately 1 second) on the
front panel of the server to power off the server, then press the Power button
again to power on the server.
From the Oracle ILOM web interface, select Host Management > Power
Control, then select Reset from the Select Action list box.
From the Oracle ILOM CLI, type: reset /System
"UEFI BIOS Boot Mode" on page 29.
