FIGURE:
Figure Legend
1
2
3
2. Starting with either the left or right side of the rack, align the rear of the
slide-rail assembly against the inside of the rear rack rail, and push until the
assembly locks into place with an audible click.
48
Sun Server X4-2 Installation Guide • February 2014
Orienting the Slide-Rail With the Ball-Bearing Track
Slide-rail
Ball-bearing track
Locking mechanism
