Accessing Oracle System Assistant; Launch Oracle System Assistant Locally - Sun Microsystems Server X4-2 Installation Manual

Oracle X4 Series Servers Administration Guide at:
■
http://www.oracle.com/goto/x86AdminDiag/docs

Accessing Oracle System Assistant

Use one of the following methods to access Oracle System Assistant:
"Launch Oracle System Assistant Locally" on page 102
■
"Launch Oracle System Assistant Using the Oracle ILOM Web Interface" on
■
page 104
Related Information
"Set Up Software and Firmware Using Oracle System Assistant" on page 105
■
"Setting Up an Operating System and Drivers" on page 106
■

▼ Launch Oracle System Assistant Locally

To launch Oracle System Assistant locally you must be present at the server and have
access to the following:
VGA monitor
■
USB keyboard
■
USB mouse
■
1. Ensure that the server is in standby power mode.
When the server is in standby power mode, the Power/OK LED on the front panel
blinks slowly.
2. Connect locally to the server.
Follow the cabling instructions in
3. Press the Power button on the front panel of the server to power on the server to
full power.
The server boots, and power-on self-test (POST) and boot messages appear on the
monitor.
Stay with the server. You need to interrupt the boot process.
102 Sun Server X4-2 Installation Guide • February 2014
"Cabling the Server" on page 75.
