Front Panel Status Indicators,
Connectors, and Drives
These sections describe the status indicators (LEDs), connectors, and drives on the
front panel of each of the drive configurations available for the Sun Server X4-2.
"Front Panel With Eight 2.5-inch Drives" on page 22
■
"Front Panel With Four 2.5-inch Drives and SATA DVD Drive" on page 24
■

Front Panel With Eight 2.5-inch Drives

The following figure shows the status indicators (LEDs), connectors, and drives on
the front panel of a Sun Server X4-2 configured with eight 2.5-inch storage drives.
22 Sun Server X4-2 Installation Guide • February 2014
