Related Information
"About the Installation Procedure" on page 1
■
"Preparing for Server Installation" on page 5
■

Installation Prerequisites

Ensure that the following tasks are complete before you start the rackmount
procedures:
Install all optional components purchased for the server. See
■
Component Installation" on page
Ensure that your site meets the required electrical and environmental
■
requirements. See

Rack Requirements

The rack into which you install the Sun Server X4-2 must meet the requirements
listed in the following table. Oracle's Sun Rack II is compatible with the Sun Server
X4-2. For information about Oracle's Sun Rack II, see
Installation" on page
TABLE:
Item
Structure
Rack horizontal opening and unit
vertical pitch
Distance between front and rear
mounting planes
Clearance depth in front of front
mounting plane
40 Sun Server X4-2 Installation Guide • February 2014
"Preparing for Server Installation" on page
5.
Rack Requirements
18.
"Preparing for Server
Requirement
Four-post rack (mounting at both front and rear).
Supported rack types: square hole (9.5 mm) and
round hole (M6 or 1/4-20 threaded only.
Two-post racks are not compatible.
Conforms to ANSI/EIA 310-D-1992 or IEC 60927
standards.
Minimum 61 cm and maximum 91.5 cm
(24 inches to 36 inches).
Distance to front cabinet door is at least 2.54 cm
(1 inch).
"Optional
5.
