Caution – Verify that the server is securely mounted in the rack and that the
slide-rail locks are engaged with the mounting brackets before you install the
optional cable management arm.
Related Information
"Install the First-Generation Cable Management Arm" on page 68
■
"Install the Second-Generation Cable Management Arm" on page 52
■
"Verify Operation of Slide-Rails and CMA" on page 73
■
▼ Install the Second-Generation Cable
Management Arm
Follow this procedure to install the second-generation cable management arm
(CMA), which you can use to manage cables connected to the rear of the server.
1. Unpack the CMA.
The following figure shows the second-generation CMA components.
52 Sun Server X4-2 Installation Guide • February 2014
Sliding the Server Into the Rack
