b. Apply upward pressure to the outside edge of each hinge connector until the
hinge connector comes off the hinge [frame 3].
Step a
c. Repeat and
d. One at a time, position each round cable cover horizontally over the hinges,
and align the hinge connectors with the hinges.
e. Using your thumb, apply downward pressure on each hinge connector to
snap the hinge connector into place.
f. Swing the cable covers down and press down on the cable cover handle to
lock them into the closed position.
4. Ensure that the six Velcro straps are threaded into the CMA as shown in
FIGURE: Second-Generation CMA Components on page
Note – Ensure that the two Velcro straps located on the front slide bar are threaded
through the opening in the top of the slide bar as shown in
Second-Generation CMA Components on page
from interfering with the expansion and contraction of the slide bar when the server
is extended out of the rack and returned into the rack.
5. To make it easier to install the CMA, extend the server approximately 13 cm (5
inches) out of the front of the rack.
6. Take the CMA to the back of the equipment rack, and ensure that you have
adequate room to work at the back of the server.
Note – References to "left" or "right" in this procedure assume that you are facing
the back of the equipment rack.
Note – Throughout this installation procedure, support the CMA and do not allow it
to hang under its own weight until it is secured at all four attachment points.
7. To install the CMA's connector A into the left slide rail:
a. Insert the CMA's connector A into the front slot on the left slide-rail until it
locks into place with an audible click [frames 1 and 2].
The connector A tab (see callout 1) goes into the slide-rail's front slot (callout 2).
b. Gently tug on the left side of the front slide bar to verify that connector A is
properly seated.
Step b
to remove all three cable covers.
53.
FIGURE:
53. This prevents the Velcro straps
