Cabling the Server

This section contains procedures for connecting data and server management cables
and power cords to the server.
Description
Review connector port locations.
Learn about server Ethernet ports.
Connect data cables to the server.
Connect power cords to the server.
Related Information
"Installation Procedure Overview" on page 2
■
"Install the Second-Generation Cable Management Arm" on page 52
■
"Install the First-Generation Cable Management Arm" on page 68
■
"Setting Up Software and Firmware Using Oracle System Assistant" on page 101
■
"Connecting to Oracle ILOM" on page 81
■

Rear Cable Connections and Ports

The following figure shows the locations of cable connectors and ports on the back of
the Sun Server X4-2 and the cables and devices that you would typically connect to
them.
Links
"Rear Cable Connections and Ports" on
page 75
"Ethernet Ports" on page 77
"Attaching Data Cables to the Server" on
page 78
"Connecting Power Cords to the Server" on
page 79
