Note – The slide-rail latching bracket has a green release tab. This tab is used to
release and remove the latching bracket so that you can remove connector D.
12. Gently tug on the four CMA connection points to ensure that the CMA
connectors are fully seated before you allow the CMA to hang by its own
weight.
13. To verify that the slide-rails and the CMA are operating properly before routing
cables through the CMA:
a. Extend all rack anti-tilt devices to prevent the rack from tipping forward
Caution – To reduce the risk of personal injury, stabilize the expansion rack cabinet
and extend all anti-tilt devices before extending the server from the rack.
b. Extend the server from the front of the rack until the CMA is fully extended.
60 Sun Server X4-2 Installation Guide • February 2014
when the server is extended.
For instructions for stabilizing the rack, see
on page 43.
"Stabilize the Rack for Installation"
