(Continued)
Figure Legend
5 System status indicators:
Locator LED: white
Service Required LED: amber
Power/OK LED: green
6 PCIe card slot 1 (Nonfunctional in
single-processor systems.)
7 PCIe card slot 2
8 PCIe card slots 3 and 4
Related Information
"Front Panel Status Indicators, Connectors, and Drives" on page 22
■
"Server Components" on page 20
■

Server Management Software Overview

The following sections describe the server management software:
"Oracle System Assistant" on page 26
■
"Oracle ILOM Overview" on page 27
■
"UEFI BIOS Overview" on page 28
■

Oracle System Assistant

Oracle System Assistant allows you to set up and manage the Sun Server X4-2. The
Oracle System Assistant application is a task-based server provisioning tool that
allows you to perform initial server setup and maintenance for Oracle x86 servers.
Using Oracle System Assistant, you can install a supported Oracle Solaris, Oracle
VM, Linux, or Windows operating system, update your server to the latest software
release, and configure server hardware.
The Sun Server X4-2 might contain an internal USB flash drive that contains Oracle
System Assistant.
26 Sun Server X4-2 Installation Guide • February 2014
13 Network (NET) 100/1000/10000 port: NET 1
14 Network (NET) 100/1000/10000 port: NET 0
15 USB 2.0 connectors (2)
16 DB-15 video connector
