▼ Configure RAID on Storage Drives Using a Sun
Storage 6 Gb SAS PCIe RAID Internal HBA
1. Launch Oracle System Assistant.
See "Accessing Oracle System Assistant" on page
The Oracle System Assistant System Overview screen appears.
2. In the System Overview screen, verify that the BIOS Mode is set to the boot
mode (UEFI or Legacy BIOS) that you plan to use when you install the
operating system.
Note – The BIOS mode used for the RAID configuration must match the BIOS boot
mode of the operating system with which you intend to use the RAID configuration.
For instructions for switching the BIOS mode from UEFI to Legacy BIOS, or vice
versa, see the Oracle X4 Series Servers Administration Guide at
http://www.oracle.com/goto/x86AdminDiag/docs. Additionally, not all
supported operating systems support UEFI mode. For a list of operating systems that
support UEFI mode, see
3. Click the Configure Hardware button, then select the RAID Configuration tab.
The RAID Configuration screen appears.
"UEFI BIOS Boot Mode" on page
Configuring Server Drives for OS Installation
102.
29.
121
