Sun Microsystems Server X4-2 Installation Manual page 35

Sun Server X4-2 Components (Continued)
TABLE:
Feature
Ethernet ports
USB 2.0 ports
Video (VGA) ports
Service processor (SP) The server includes an AST2300 service processor (SP). The SP
Management
Software
Power supplies
Cooling fans
Operating systems
Virtualization
software
Related Information
"Front Panel Status Indicators, Connectors, and Drives" on page 22
■
"Back Panel Status Indicators, Connectors, and PCIe Slots" on page 25
■
Description
Up to four 10GBASE-T RJ-45 Gigabit Ethernet (10GbE) ports on the
rear panel.
Note - Ethernet ports NET 2 and NET 3 are nonfunctional in
single-processor systems.
Two front, two rear, and two internal.
Note - One of the internal USB ports might be preinstalled with a
USB drive containing the Oracle System Assistant. For more
information, see the Oracle X4 Series Servers Administration Guide at
http://www.oracle.com/goto/x86AdminDiag/docs.
One rear high-density DB-15 video port.
provides IPMI 2.0 compliant remote management capabilities. The SP
features:
• Oracle Integrated Lights Out Manager (ILOM) version 3.1.
• Local Oracle ILOM command-line access using a serial connection.
• Support for Ethernet access to SP through a dedicated,
10/100BASE-T management port (NET MGT) and optionally
through one of the host Ethernet ports (sideband management).
• Support for remote KVMS (keyboard, video, mouse, and storage)
over IP.
• Oracle Integrated Lights Out Manager (ILOM) 3.1
• Oracle System Assistance 1.1
• Oracle Hardware Management Pack 2.2
Two hot-swappable and highly-redundant 600W power supplies.
Four 40-mm, hot-swappable fan modules for chassis cooling. Each
fan module contains two counter-rotating fan pairs (four rotors total).
Each power supply has its own cooling fans.
• Oracle Solaris and Oracle Linux operating systems can be
optionally preinstalled on the server.
• Oracle Solaris, Linux, and Windows are supported. For a complete
list of supported OS versions for your server, refer to the Sun Server
X4-2 Product Notes at:
http://www.oracle.com/goto/X4-2/docs
• Oracle VM and VMware ESXi are supported.
• Oracle VM software can be optionally preinstalled on the server.
About Server Features and Components 21
