4. To disconnect connector D:
a. Press the green release tab (callout 1) on the slide-rail latching bracket
toward the left and slide the connector D out of the left slide-rail [frames 1
and 2].
Note – When you slide connector D out of the left slide-rail, the slide-rail latching
bracket portion of the connector remains in place. You will disconnect it in the next
step.
Note – Once you have disconnected connector D, you must not allow the CMA to
hang under its own weight. Throughout the remainder of this procedure, the CMA
must be supported until all the remaining connectors are disconnected and the CMA
can be placed on a flat surface.
Installing the Server Into a Rack
65
