Installing a Disk Drive

007-4566-001
To install a disk drive, follow these steps:
1. Open the bezel door as far as it will open. Position the drive assembly so that it
engages the bay guide rails and, with the locking handle fully swung open, gently
push the drive into the bay until the locking handle engages with left side of the bay
opening, as shown in Figure 6-19A.
Note: If you will have only one disk drive in your system, it should be located in the
bottom-most slot.
2. Swing the locking handle towards the chassis until the locking handle engages the
latch, as shown in Figure 6-19B and Figure 6-19C.
3. Close the bezel door, as shown in Figure 6-19D.
