1: Installation and Operation

Operating the L1 Controller

62
Failure LED
Service-required LED
Figure 1-33 Front Panel Functions
The L1 controller operates in one of the two following modes:
• L1 mode. The L1 prompt (
command processor.
• Console mode from L1. Output from the system is visible and all input is directed
to the system.
The L1 controller is ready to accept commands when you see a prompt of the following
form:
001c01-L1>
See the SGI L1 and L2 Controller Software User's Guide (007-3938-00x) for a detailed list of
L1 commands.
L1 controller display
Reset
Power button
with LED
) is visible and all input is directed to the L1
001c01-L1>
NMI
007-4566-001
