Figure 1-23 Installing The Shelf Rails In The Rack - Silicon Graphics Origin 350 User Manual

Front/rear
bracket
tabs
Rail
007-4566-001
Shelf rail
Figure 1-23 Installing the Shelf Rails in the Rack
9. Set the rear edge of the module on the shelf rails. Then slide the module into the
rack until the module ears are snug against the rack rails. See Figure 1-24.
10. Fasten the module to the front rails of the rack with the screws and clip nuts
provided. See Figure 1-24.
11. Fasten the module to the rear rails of the rack with the screws and clip nuts
provided.
Installing the Server System in a Rack
Shelf rail
Torx
screws
EMI
gasket
bracket
Rear view
Push-in
fasteners
43
