Unpacking and Inspecting Server System Modules

Setting the Server System on a Table Top

007-4566-001
This section is written for the person who wants to install his or her own individual
server system modules either on a rack or on a tabletop. It describes how to unpack and
inspect individual server system modules.
Before unpacking your modules, inspect the packaging container for evidence of
mishandling during transit. If the packaging container is damaged, photograph it for
reference. After you remove the contents, keep the damaged container and the packing
materials.
Remove the module or modules from the packaging container and ensure that all
accessories are included. Inspect the module(s) and accessories for damage. If the
contents appear damaged, file a damage claim with the carrier immediately. In addition,
notify your local Customer Support Center (CSC) for any missing, incorrect, or damaged
items. For CSC contact information, see
http://www.sgi.com/support/supportcenters.html.
If your server system is a single module (the base compute module) system or a
dual-module (a base compute module cabled to an MPX module, for example) system,
and you choose to operate it on a table top, you need to install five self-adhesive feet that
are supplied with the module(s). To install the feet, follow these steps:
1. Place the module upside down on a flat, stable surface.
2. Peel off the protective film from the feet and place them on the five circular marks,
as shown in Figure 1-11.
3. If you have a dual-module system, repeat steps 1 and 2 to put feet on the second
module. (If you have a dual-module system, it is recommended that you place the
base compute module on the bottom, and that you place the other module on top.)
Note: If you mount the system in a rack at a later date, you will need to remove the feet.
