1: Installation and Operation

Determining Space Requirements

Checking the Slide Rail Hardware

26
Table 1-2 specifies the space requirements when rackmounting either a base compute
module, a system expansion compute module, or an MPX module in a 19-inch rack.
Table 1-2 Module Space Requirements
Height
Width
Depth
Weight
Required front clearance for module
Required rear clearance for module
Required side clearance for module
Required front clearance for rack
Required rear clearance for rack
a. Weight will vary depending on whether the system has one or two power supplies, on the amount
of DIMMs installed, and on whether you have one or two disk drives in your system.
Table 1-3 lists the hardware that you will use to mount the module in a 19-inch rack.
Table 1-3 Rackmounting Hardware
Hardware Type
Slide rail assembly (includes
chassis rail)
2-in. rear mounting bracket
10-24 x 1/4-in. Phillips screw
3.44 inches (8.74 cm)
17.06 inches (43.33 cm)
27 inches (68.58 cm) (with bezel)
37.80 lb (17.18 kg) minimum
configuration; 44.50 lb (20.23 kg)
maximum configuration
8.25 in. (20.96 cm)
10 in. (25.40 cm)
6 in. (15.24 cm) (right side)
No clearance requirement for left side.
36 in. (91 cm)
36 in. (91 cm)
Qty Usage
2 Allows the module to slide in and out of rack.
(The left and right slides are identical.)
2 Mounts the slide rails to the rear rack rails.
(The left and right brackets are identical.)
10 Secures the chassis rails to the module.
a
007-4566-001
