Transporting the Shipping Crate

!

Removing a Short Rack from the Shipping Crate

!
007-4566-001
Use a pallet jack with forks that are 48 in. (122 cm) long or longer to transport the
shipping crate to the designated location. See Figure 1-3 and Figure 1-4 for the crate
dimensions and location to position the pallet jack. For system weight and dimensions,
contact site planning by e-mail (site@sgi.com) or by telephone (+1 715 726 2820).
If the crate does not fit through all access doors, you may need to partially disassemble
the crate.
Caution: If the system shipping or storage environment is significantly colder than the
environment in which it will be installed [40
in its shipping crate for at least 24 hours at room temperature before you start the
installation. This acclimation prevents damage to the equipment that could result from
thermal shock and condensation.
Warning:
Be careful when you unpack and move the short rack system. Ensure that
the rack remains on a level surface and that the rack weight remains evenly
distributed across the four casters. If you must lift the casters over an obstacle, such as
a door threshold, use proper lifting techniques and employ a minimum of two people.
Caution: Do not subject the rack to any unnecessary shocks or vibration while you
unpack and install the system.
See Figure 1-5 as you follow these steps; the numbered illustrations correspond to the
numbered steps.
1. Ensure that the temperature of the rack is acclimated to the environment in which
you are installing it.
2. Remove the crate cover.
3. Lift the ramp out of the crate and set it aside.
4. Remove the documentation carton, accessories carton, and cardboard packing
material.
5. Lift the sidewalls of the crate up and over the system.
F (22 C) or greater disparity], leave the rack
º º
Installing a Rack
13
