SCSI VHDCI Pin Assignments (continued)
Table A-22
Pin Number Signal Name
16 DIFFSENS
17 TERMPWR
18 TERMPWR
19 Reserved
20 Ground
21 +ATN
22 Ground
23 +BSY
24 +ACK
25 +RST
26 +MSG
27 +SEL
28 +CD
29 +REQ
30 +IO
31 +DB (8)
32 +DB (9)
33 +DB (10)
34 +DB (11)
Non-proprietary I/O Port Specifications
Pin Number Signal Name
50 Ground
51 TERMPWR
52 TERMPWR
53 Reserved
54 Ground
55 -ATN
56 Ground
57 -BSY
58 -ACK
59 -RST
60 -MSG
61 -SEL
62 -CD
63 -REQ
64 -IO
65 -DB (8)
66 -DB (9)
67 -DB(10)
68 -DB (11)
